ATM60 ATM60-D4H13x13, Product data sheet - SICK Proximity Photoelectric Sensor | part no : 1030017
  • Name

ATM60 ATM60-D4H13x13, Product data sheet - SICK Proximity Photoelectric Sensor | part no : 1030017

MOQ: 1
Price: $403/piece
Standard Packaging: 110*60*60mm
Delivery Period: 3 day
Payment Method: T/T
Supply Capacity: 1piece in stock
Details Information
Product Description
Detail Information
Place of Origin
GERMANY
Brand Name
SICK
Certification
3C
Model Number
ATM60-D4H13x13
Initialization Time:
1,250 Ms
Weight:
0.59 Kg
Permissible Relative Humidity:
98 %
Operating Temperature Range:
–20 °C ... +85 °C
Storage Temperature Range:
–40 °C ... +100 °C, Without Package
Product Description
Performance
Number of steps per revolution (max. resolu-
tion)		 8,192 (13 bit)
Number of revolutions 8,192 (13 bit)
Max. resolution (number of steps per revolu-
tion x number of revolutions)		 13 bit x 13 bit (8,192 x 8,192)
Measuring step 0.043°
Error limits G ± 0.25° 1)
Repeatability standard deviation σr 0.1° 2)
1) In accordance with DIN ISO 1319-1, position of the upper and lower error limit depends on the installation situation, specified value refers to a symmetrical position,
i.e. deviation in upper and lower direction is the same.
2) In accordance with DIN ISO 55350-13; 68.3% of the measured values are inside the specified area.
Interfaces
Communication interface DeviceNet™
Data protocol DeviceNet Specification Release 2.0
Address setting 0 ... 63, DIP switches or protocol
Data transmission rate (baud rate) 125 kBaud, 250 kBaud, 500 kBaud, DIP switches or protocol
Initialization time 1,250 ms 1)
Position forming time 0.25 ms
Status information Network status LED, 2-colours
Bus termination DIP switch 2)
Set (electronic adjustment) Via PRESET push button or protocol
1) Valid positional data can be read once this time has elapsed.
2) Should only be connected in the final device.
Electrical data
Connection type Bus adapter 1)
Supply voltage 10 ... 32 V
1) Order bus adapter separately.
2) This product is a standard product and does not constitute a safety component as defined in the Machinery Directive. Calculation based on nominal load of com-
ponents, average ambient temperature 40°C, frequency of use 8760 h/a. All electronic failures are considered hazardous. For more information, see document no.
8015532.
2 ABSOLUTE ENCODERS | SICK Product data sheet | 2024-07-17 16:39:44
  Subject to change without notice
  ATM60-D4H13x13 | ATM60
    ABSOLUTE ENCODERS
Power consumption ≤ 2 W (without load)
Reverse polarity protection √
MTTFd: mean time to dangerous failure 150 years (EN ISO 13849-1) 2)
1) Order bus adapter separately.
2) This product is a standard product and does not constitute a safety component as defined in the Machinery Directive. Calculation based on nominal load of com-
ponents, average ambient temperature 40°C, frequency of use 8760 h/a. All electronic failures are considered hazardous. For more information, see document no.
8015532.
Mechanical data
Mechanical design Solid shaft, face mount flange
Shaft diameter 10 mm
Shaft length 19 mm
Weight 0.59 kg 1)
Shaft material Stainless steel
Flange material Aluminum
Housing material Aluminum die cast
Start up torque 2.5 Ncm (+20
0.5 Ncm (+20		 °C), with shaft seal
°C), without shaft seal		 2)
Operating torque 1.8 Ncm (+20
0.3 Ncm (+20		 °C), with shaft seal
°C), without shaft seal		 2)
Permissible shaft loading 300 N (radial)
50 N (axial)
Operating speed ≤ 6,000 min⁻¹ 3)
Moment of inertia of the rotor 35 gcm²
Bearing lifetime 3.6 x 109 revolutions
Angular acceleration ≤ 500,000 rad/s²
1) Based on encoder with male connector.
2) If the shaft seal has been removed by the customer.
3) Allow for self-heating of 3.3 K per 1,000 rpm when designing the operating temperature range.
Ambient data
EMC According to EN 61000-6-2 and EN 61000-6-3
Enclosure rating IP67, with shaft seal (IEC 60529) 1)
IP43, without shaft seal, on encoder flange not sealed (IEC 60529)
IP66, without shaft seal, on encoder flange sealed (IEC 60529) 1)		 1)
Permissible relative humidity 98 %
Operating temperature range –20 °C ... +85 °C
Storage temperature range –40 °C ... +100 °C,without package
Resistance to shocks 100 g, 6 ms (EN 60068-2-27)
Resistance to vibration 20 g, 10 Hz ... 2,000 Hz (EN 60068-2-6)
1) With mating connector fitted.
Classifications
ECLASS 5.0 27270502
ECLASS 5.1.4 27270502
ECLASS 6.0 27270590
2024-07-17 16:39:44 | Product data sheet ABSOLUTE ENCODERS | SICK 3
Subject to change without notice
ATM60-D4H13x13 | ATM60
ABSOLUTE ENCODERS
ECLASS 6.2 27270590
ECLASS 7.0 27270502
ECLASS 8.0 27270502
ECLASS 8.1 27270502
ECLASS 9.0 27270502
ECLASS 10.0 27270502
ECLASS 11.0 27270502
ECLASS 12.0 27270502
ETIM 5.0 EC001486
ETIM 6.0 EC001486
ETIM 7.0 EC001486
ETIM 8.0 EC001486
UNSPSC 16.0901 41112113
