WL12L-2B530 SICK Retroreflective Photoelectric Sensor Part No 1018252

MOQ:	1
Price:	205$/piece
Standard Packaging:	1106060mm
Delivery Period:	3 day
Payment Method:	T/T
Supply Capacity:	1piece in stock

Details Information

Product Description

Detail Information

Place of Origin

GERMANY

Brand Name

Certification

Model Number

WL12L-2B530

Dimensions (W x H x D):

15 Mm X 49 Mm X 41.5 Mm

Switching Frequency:

2,500 Hz

Weight:

130 G

Enclosure Rating:

IP67 IP69K

Ambient Operating Temperature:

–10 °C ... +50 °C

Ambient Temperature, Storage:

–25 °C ... +75 °C

Highlight:

WL12L-2B530 Retroreflective Photoelectric Sensor

1018252 Retroreflective Photoelectric Sensor

SICK Retroreflective Photoelectric Sensor

Product Description

Features

Sensor/ detection principle

Photoelectric retro-reflective sensor, autocollimation

Dimensions (W x H x D)

15 mm x 49 mm x 41.5 mm

Housing design (light emission)

Rectangular

Sensing range max.

0 m ... 18 m 1)

Type of light

Visible red light

Light source

Laser 2)

Light spot size (distance)

Ø 0.8 mm (300 mm)

Wave length

650 nm

Laser class

2 (EN 60825-1:2014, IEC 60825-1:2007) 3)

Adjustment

Potentiometer

Special applications

Detecting small objects, Detection of objects moving at high speeds

Special features

Focusable from 300 mm to infinite

Reflector PL80A.

Average service life: 50,000 hat TU = +25 °C.

Pulse length 4 µs, max. pulse power < 5,0 mW.

2 PHOTOELECTRIC SENSORS | SICK Product data sheet | 2021-03-26 18:13:39

Subject to change without notice

WL12L-2B530 | W12-2 Laser

SMALL PHOTOELECTRIC SENSORS

Mechanics/electronics

Supply voltage

10 V DC ... 30 V DC 1)

Ripple

< 5 Vpp

Current consumption

55 mA 3)

Switching output

PNP
NPN

4)
5)

Switching mode

Light switching
Dark switching

4)
5)

Switching modeselector

Selectable via L/Dcontrol cable

Signal voltage PNP HIGH/LOW

Uv - < 2.9 V, Uv V / 0 V <= 1.5 V

Signal voltage NPN HIGH/LOW

Uv - < 2.9 V, Uv V / 0 V <= 1.5 V

Output current Imax.

≤ 100 mA

Response time

≤ 200 µs

Switching frequency

2,500 Hz 7)

Connection type

Male connector M12, 5-pin

Circuit protection

A 8)
C 9)
D 10)

Protection class

III

Weight

130 g

Polarisation filter

✔

Housing material

Metal

Optics material

Plastic, PMMA

Enclosure rating

IP67
IP69K

Items supplied

2 x clamps BEF-KH-W12, incl. screws

Ambient operating temperature

–10 °C ... +50 °C

Ambient temperature, storage

–25 °C ... +75 °C

UL File No.

NRKH.E181493 & NRKH7.E181493

1) Limit values when operated in short-circuit protected network: max. 8 A.
2) May not exceed or fall below Uv tolerances.
3) Without load.

4) 0 V or not connected, light switching.
5) Uv, dark switching.

6) Signal transit time with resistive load.
7) With light/dark ratio 1:1.

8) A = VS connections reverse-polarity protected.
9) C = interference suppression.

10) D = outputs overcurrent and short-circuit protected.
Safety-related parameters

MTTFD

226 years

DCavg

Classifications

ECl@ss 5.0 27270902

2021-03-26 18:13:39 | Product data sheet PHOTOELECTRIC SENSORS | SICK 3

Subject to change without notice

WL12L-2B530 | W12-2 Laser

SMALL PHOTOELECTRIC SENSORS

ECl@ss 5.1.4

27270902

ECl@ss 6.0

27270902

ECl@ss 6.2

27270902

ECl@ss 7.0

27270902

ECl@ss 8.0

27270902

ECl@ss 8.1

27270902

ECl@ss 9.0

27270902

ECl@ss 10.0

27270902

ECl@ss 11.0

27270902

ETIM 5.0

EC002717

ETIM 6.0

EC002717

ETIM 7.0

EC002717

UNSPSC 16.0901

39121528
