SICK Laser Sensor YF2A14-020UB3XLEAX Part No 2095607

SICK Laser Sensor YF2A14-020UB3XLEAX Part No 2095607

MOQ: 1
Price: $22/piece
Standard Packaging: 80*50*50mm
Delivery Period: 3 day
Payment Method: T/T
Supply Capacity: 1piece in stock
Detail Information
Place of Origin
GERMANY
Brand Name
SICK
Certification
3C
Model Number
YF2A14-020UB3XLEAX
Jacket Color:
Black
Connector Material:
TPU
Cable Diameter:
45mm
Highlight:

SICK YF2A14-020UB3XLEAX

,

2095607 SICK Laser Sensor

Product Description
Technical specifications
Accessory group Plug connectors and cables
Accessory family Connecting cables
Connection type head A Female connector, M12, 4-pin, straight, A-coded
Connection type head B Flying leads
Locking plug connector Screw connection
Connector material TPU
Connector color Black
Locking nut material Zinc die-cast, nickel-plated
Seal material FKM
Tightening torque 0.6 Nm
Width across flats 13
Cable 2 m, 4-wire, PUR, halogen-free
Jacket material PUR, halogen-free
Jacket color Black
Cable diameter 4.5 mm
Conductor cross-section 0.34 mm²
Shielding Unshielded
Bending radius
Flexible use

Stationary position
Drag chain operation

> 10 x cable diameter
> 5 x cable diameter
> 10 x cable diameter

Bending cycles 10,000,000
Reference voltage ≤ 250 V DC
Rated impulse voltage 2.5 kV
Current loading 4 A
Traversing speed 3 m/s
Travelling distance 10 m
Acceleration ≤ 10 m/s²
2 | SICK Product data sheet | 2021-05-04 23:25:55
  Subject to change without notice
  YF2A14-020UB3XLEAX
Signal type Sensor/actuator cable
Torsion force 180° / 1 m
Torsion cycles 2,000,000
Cycles per minutes 35
Application Zones with oils and lubricants
Drag chain operation

Authorizations CE
UL

UL File No. E335179
Enclosure rating IP65 / IP66K / IP67
Ambient operating temperature
Flexible use

Stationary position
Drag chain operation
Head

–25 °C ... +80 °C

–40 °C ... +80 °C

–25 °C ... +80 °C

–25 °C ... +85 °C

Contamination rating 3
Insulation resistance 100 MΩ
Overvoltage category III
Specific insulation resistance 30 mΩ
Thermal resistance, cable Flame retardant according to UL 1581, horizontal flame test/CSA FT2 / IEC 60332-1,
IEC 60332-2-2
