SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891

SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891

MOQ: 1
Price: $53/piece
Delivery Period: 3 day
Payment Method: T/T
Supply Capacity: 1piece in stock
Detail Information
Place of Origin
GERMANY
Brand Name
SICK
Certification
3C
Model Number
IME08-04NPOZW2K
Thread Size:
M8 X 1
Part No:
1040891
Highlight:

IME08-04NPOZW2K PROXIMITY SENSORS

,

SICK IME08-04NPOZW2K

,

SICK PROXIMITY SENSORS

Product Description
IME08-04NPOZW2K
IME


SICK
INDUCTIVE PROXIMITY SENSORS Sensor Intelligence.
SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891 0
SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891 1IME08-04NPOZW2K | IME
INDUCTIVE PROXIMITY SENSORS
Ordering information
  Type Part no.
  IME08-04NPOZW2K 1040891
  Included in delivery: BEF-MU-M08 (1)
  Other models and accessories → www.sick.com/IME
Illustration may differ
SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891 2 SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891 3 SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891 4 SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891 5
LISTED
SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891 6UK
SICK IME08-04NPOZW2K IMEINDUCTIVE PROXIMITY SENSORS Part No 1040891 7
Detailed technical data
Features
Housing Metric
Housing Short-body
Thread size M8 x 1
Diameter Ø 8 mm
Sensing range Sn 4 mm
Safe sensing range Sa 3.24 mm
Installation type Non-flush
Switching frequency 4,000 Hz
Connection type Cable, 3-wire, 2 m
Switching output PNP
Output function NC
Electrical wiring DC 3-wire
Enclosure rating IP67 1)
Items supplied Mounting nut, brass, nickel-plated (2x)
1) According to EN 60529.
Mechanics/electronics
Supply voltage 10 V DC ... 30 V DC
Ripple ≤ 10 %
Voltage drop ≤ 2 V 1)
Time delay before availability ≤ 100 ms
1) At Ia max.
2) Supply voltage U B and constant ambient temperature Ta.
3) Of Sr.
2 INDUCTIVE PROXIMITY SENSORS | SICK Product data sheet | 2024-11-07 07:58:34
  Subject to change without notice
  IME08-04NPOZW2K | IME
  INDUCTIVE PROXIMITY SENSORS
Hysteresis 5 % ... 15 %
Reproducibility ≤ 2 % 2) 3)
Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2
Continuous current Ia ≤ 200 mA
No load current ≤ 10 mA
Cable material PVC
Conductor size 0.25 mm²
Cable diameter Ø 3.9 mm
Short-circuit protection
Power-up pulse protection
Shock and vibration resistance 30 g, 11 ms/10 Hz ... 55 Hz, 1 mm
Ambient operating temperature –25 °C ... +75 °C
Housing material Brass, nickel-plated
Sensing face material Plastic, PA 66
Housing length 43 mm
Thread length 21 mm
Tightening torque, max. ≤ 5 Nm
UL File No. NRKH.E181493
1) At Ia max.
2) Supply voltage U B and constant ambient temperature Ta.
3) Of Sr.
