Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical
  • Name
  • Name
  • Name
  • Name
  • Name
  • Name

Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical

MOQ: 1
Price: variable
Standard Packaging: Carton
Delivery Period: Negotiate
Payment Method: T/T
Supply Capacity: 100PCS/MONTHS
Details Information
Product Description
Detail Information
Place of Origin
Germany
Brand Name
Euchner
Certification
UL,CCC,etc.
Model Number
SN03D12-502-M
Manufacturer:
Euchner
Product NO.:
SN03D12-502-M
Product Type:
Limit Switch Series
Warranty:
1 Year
Moq:
1 Set
Highlight:

mechanical Euchner SN03D12-502-M Limit Switch

,

Euchner SN03D12-502-M Limit Switch

Product Description



Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical





Specification



Part Number: SN03D12-502-M
Manufacturer: Euchner
Condition : Brand New
Warranty : 12 months
Product Type Limit Switch Series





Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 0



Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 1





Electrical connection values

Connection cross section 0.34 ... 1.5 mm²
Rated insulation voltage Ui 250 V
Rated impulse withstand voltage Uimp 2.5 kV
Utilization category
AC-12 8 A 250 V
DC-13 6 A 24 V
AC-15 6 A 230 V
Short circuit protection according to IEC 60269-1 8A gG
Switching current
min. at DC 12V min. 10 mA
thermal rated current Ith 8 A

Mechanical values and environment

Approach speed 0.01 ... 40 m/min
Connection type
2 x M20 x 1.5
Number NC contacts 3
Number of switching elements 3
Number of NO contacts 3
Design upright
Actuating element Chisel plunger
Actuating force min. 20 N
Installation orientation any
Mechanical life 30 x 10⁶
Switching principle Snap-action switching contact
Degree of protection IP67
Plunger spacing 12 mm
Ambient temperature -5 ... +80 °C
Material
Housing Die-cast aluminum, anodized
Contact Silver alloy, gold flashed

Cooperative Brand



Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 2



Packaging & Shipping



Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 3Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 4

Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 5

Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 6



Why Choose Us



Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 7

Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 8Euchner SN03D12-502-M (ORDER NO. 082164) Limit Switch Series SN... 12 mm, mechanical 9







Xiamen ZhiCheng Automation Technology Co., Ltd

Xiamen ZhiCheng Automation Technology Co., Ltd it is a leading global supplier of control system components. We specialize in control systems and drives.

With many years of experience in the industrial sector, we consistently deliver the highest quality of spare parts. We have tens of thousands of spare partsand spare parts warehouse . Products and services to serve for installing of users control system,Distributed control systems, programmable controllers, panel controller and drive!

We major in DCS system,Sensor,PLC,Connector,Valve, and Instrument,MAGNETRON,RO Membrane. With many years of experience in the industrial sector, we consistently deliver the highest quality of spare parts.which make sure that all this jobs are perfectly.

If you have any further questions, please don't hesitate to contact us.
