MOQ: | 1 |
Price: | variable |
Standard Packaging: | Carton |
Delivery Period: | Negotiate |
Payment Method: | T/T |
Supply Capacity: | 100PCS/MONTHS |
Euchner N1AR502SVM5-M (ORDER NO. 087488) Precision single limit switch N1A, roller plunger, plug connector M12
Specification
|
Rated insulation voltage Ui | 50 V |
Rated impulse withstand voltage Uimp | 1.5 kV |
Utilization category | |
AC-15 | 4 A 30 V |
DC-13 | 4 A 24 V |
Short circuit protection according to IEC 60269-1 | 4A gG |
Switching current | |
min. at DC 12V | 10 mA |
thermal rated current Ith | 4 A |
Approach speed | 0.01 ... 80 m/min |
Connection type | |
1 x | Plug connector M12 |
Number NC contacts | 1 |
Number of switching elements | 1 |
Number of NO contacts | 1 |
Design | Housing according to DIN 43693 |
Actuating element | Roller plunger |
Actuating force | min. 20 N |
Installation orientation | any |
Mechanical life | 30 x 10⁶ |
Contact bounce time | < 3ms |
Roller diameter | 8 |
Switching principle | Snap-action switching contact |
Operating point accuracy | ± 0,01 |
Contact closing time | < 4ms |
Degree of protection | IP67 |
Ambient temperature | -5 ... +80 °C |
Material | |
Contact | Silver alloy, gold flashed |
Housing | Anodized die-cast alloy |
