Harting 09160243001 Industrial Plug Heavy-Duty Connector with IP68/Metal Housing IP65/67 Protection and 630V Rated Voltage for Industrial Machinery

1. Product Overview and Technical Specifications

​
The HARTING 09160243001 is a high-performance heavy-duty connector designed for robust industrial automation applications. This modular connector system features a zinc die-cast housing with IP65/67 protection rating, ensuring reliable operation in harsh environments exposed to dust, moisture, and mechanical stress. The connector supports current ratings up to 100A and voltage ratings of 630V, complying with IEC 61076 standards. Key technical parameters include an operating temperature range from -40°C to +125°C, contact resistance of <0.5mΩ, and insulation resistance >5000MΩ. The modular contact configuration allows flexible arrangements of power, signal, and data contacts within a single housing. The connector utilizes a secure locking mechanism with visual mating indication and offers various coding options to prevent mismating. These features make it ideal for demanding industrial applications requiring reliable power distribution and signal transmission.

​2. Application Advantages and Functional Benefits

​
This heavy-duty connector excels in industrial automation, renewable energy, and transportation applications where reliable connectivity is critical. The modular design allows customized configurations for power supplies (up to 100A), signal transmission, and data communication including Ethernet. Key advantages include reduced installation time through pre-assembled modules, high vibration resistance suitable for mobile equipment, and maintenance-friendly design for quick servicing. The IP67 rating ensures reliable performance in outdoor applications and harsh environments. These benefits contribute to lower total cost of ownership through reduced downtime, easier maintenance, and long-term reliability. The connector's scalability supports system expansions and modifications, making it suitable for evolving automation systems across manufacturing, energy, and infrastructure sectors.

​3. System Integration and Performance Features

​
The connector enables seamless integration into complex automation systems through its modular and scalable design. Performance features include high-current contacts with silver plating for optimal conductivity, shielded modules for EMI protection, and color-coded housings for easy identification. The push-pull locking mechanism ensures secure connections while allowing quick disconnection when needed. The system supports various industrial protocols and can integrate power, data, and signal contacts in a single connector, reducing cabinet space requirements. These characteristics make it particularly valuable for applications requiring reliable connections in vibrating environments, such as robotic systems, wind turbines, and industrial machinery, while supporting future expansions and technology upgrades in modern industrial automation environments.
