IRAYPLE AX5E07MG250 High-FPS/FFC-Calibration Ind-Vision-Camera Large-Cache-Stability

Product Overview

The IRAYPLE AX5E07MG250 is a high-performance, network-ready uncooled microbolometer infrared camera core module engineered for reliable integration into advanced industrial automation and machine vision systems. It features a Gigabit Ethernet (GigE) interface providing 1 Gbps data bandwidth and supporting transmission distances up to 100 meters for flexible system layout.

The core module delivers thermal imaging with defined resolution and good thermal sensitivity, characterized by competitive Noise Equivalent Temperature Difference (NETD). It incorporates a thermoelectric cooler (TEC) for consistent detector temperature stabilization, ensuring measurement accuracy.

Key specifications include 256MB onboard cache for reliable data handling, support for software, hardware, and free-run trigger modes, and a comprehensive suite of on-board Image Signal Processing (ISP) functions. The device is fully compliant with GigE Vision protocol and GenICam standard and carries international certifications including CE, UKCA, UL, KC, and RoHS.

Applications & Advantages

This thermal imaging core is designed for industrial applications requiring dependable, networked thermal data, including 24/7 process monitoring, automated quality inspection, and predictive maintenance systems.

Advantages include robust network connectivity, reliable data integrity via onboard cache, and powerful onboard ISP that reduces host PC load. The integrated ISP engine—including gamma correction, lookup tables, flat-field correction (FFC), denoising, and sharpening—delivers calibrated, analysis-ready video streams.

Functionally, it enables accurate temperature measurement, thermal anomaly detection, and early fault identification. Designed for OEM integration, it serves as a smart sensor node feeding critical data into Industrial IoT (IIoT) platforms to enhance operational intelligence, support preventive maintenance, and improve system efficiency and safety.

Technical Specifications

Parameter Category	Specification Details
Model	AX5E07MG250 / AX5E07MG250E
Series	AX Series Large Area Scan Camera
Sensor	Customized, Global Shutter
Sensor Type	29.9 mm × 16.0 mm CMOS
Resolution	9344 × 5000 (46.7 MP)
Color / Mono	Mono
Frame Rate	2.6 fps
Pixel Size	3.2 μm × 3.2 μm
Bit Depth	12 bit
Dynamic Range	66 dB
Signal-to-Noise Ratio	40 dB
Image Formats	Mono8 / Mono10 / Mono10Packed / Mono12 / Mono12Packed
Exposure Time	16 μs ~ 15 s
Gain	1 ~ 32 (digital)
Gamma	0 ~ 4 (supports LUT)
Binning	1×2, 2×1, 2×2
ROI	Supported
X Flip / Y Flip	Supported
Trigger Modes	Software Trigger, Hardware Trigger, Free Run
User Configurations	2 sets of user-defined configurations
On-board Cache	512 MB
Data Interface	GigE
GPIO	3× opto-isolated input, 3× opto-isolated output, 1× RS232
Lens Mount	M58 × 0.75
Power Supply	DC 12V ~ 26V via 12-pin Hirose interface
Power Consumption	24V ≈ 8.4 W
Dimensions	72 mm × 72 mm × 65 mm (excluding rear case connector)
Weight	482 g
Operating Temperature	-30℃ ~ +50℃
Storage Temperature	-30℃ ~ +80℃
Compatibility	GigE Vision V2.0, GenICam, CE, FCC, KC, RoHS
Key Features	SPC, FFC, Auto Exposure/Auto Gain/Auto BlackLevel, fan speed adaptive control, patented flatness mediation scheme
