TP4102-E00-G00-S01 - Eddy Current Vibration Sensor - 10mV/mm/s IP67 Stainless Industrial Probe

1. Extreme-Temperature Vibration Sensor Overview​

The ProvibTech TP4102-E00-G00-S01 is a specialized piezoelectric accelerometer engineered for ultra-high-temperature industrial environments. Featuring a ​robust 316 stainless steel housing​ with ​integral mineral-insulated cable, this sensor operates reliably at ​​+250°C continuous exposure (S01 suffix)​. Utilizing ​pure shear quartz crystal technology (G00 designation)​, it delivers stable ±10% sensitivity (100mV/g) across a ​0.5Hz–8kHz frequency range (E00 standard filter)​. The hermetic laser-welded construction achieves ​IP68/IP69K protection​ against high-pressure steam cleaning and chemical exposure. Certified for ​ATEX/IECEx Zone 21​ and ​SIL 2 compliance, this accelerometer enables critical vibration monitoring in gas turbines, industrial ovens, and steam processes where conventional sensors fail. The 1-meter MI cable terminates in a radial connector for secure field connections in confined spaces.

​2. Critical Technical Specifications​

• ​Performance Parameters:
  Temperature Range: -55°C to +250°C (peak 300°C)
  Sensitivity: 100mV/g ±10% @ 25°C
  Frequency Response: 0.5Hz–8kHz (±3dB)
• ​Electrical Characteristics:
  Output: Charge mode (3pC/g) / IEPE optional
  Insulation Resistance: >10¹³Ω @ 25°C
  Capacitance: 500pF ±20%
• ​Mechanical Construction:
  Housing: 316 stainless steel
  Mounting: M5×0.5 threaded stud
  Weight: 45g
• ​Environmental Resilience:
  Shock Limit: 5,000g
  Vibration Limit: 1,000g RMS
  Hermetic Seal: <1×10⁻⁸ cc/sec helium leak rate
• ​Certifications:
  ATEX II 2G Ex ia IIC T250°C Ga
  IECEx Ex ia IIC T250°C Ga

​3. High-Temperature Industrial Applications​

This sensor excels in extreme thermal environments:

• ​Gas Turbine Exhausts: Monitoring blade-pass frequencies at 400°C+
• ​Industrial Kilns: Roller bearing monitoring in ceramic/pulp drying ovens
• ​Steam Turbine Casings: Vibration analysis during 300°C steam cycles
• ​Cracking Furnaces: Tube vibration detection in petrochemical plants
• ​Cement Rotary Kilns: Gear mesh monitoring near burning zones
• ​Aerospace Test Rigs: Jet engine component testing
• ​Metal Heat Treatment: Conveyor roller monitoring in annealing lines
• ​Nuclear Reactor Coolant Pumps: Primary loop vibration surveillance
  The mineral-insulated cable (MgO core) maintains signal integrity at 250°C where standard PUR/PVC cables degrade, while hermetic sealing prevents oxidation in reactive atmospheres.

​4. Functional Advantages​

• ​Thermal Stability:
  <±0.05%/°C sensitivity drift from -55°C to +250°C
  Quartz crystal maintains linearity at 300°C
• ​Hazardous Area Safety:
  Intrinsically safe design (Ui=5V, Ii=10mA, Pi=0.015W)
  Galvanic isolation >500V
• ​Mechanical Robustness:
  Withstands 100g mechanical shock (MIL-STD-810H)
  Vibration survival: 1,000g RMS (10Hz-10kHz)
• ​Signal Integrity:
  Low-noise (<50μg/√Hz) quartz sensing
  EMI/RFI immunity >120dB
• ​Installation Reliability:
  M5 mounting fits standard high-temp pads
  Mineral-insulated cable resists abrasion/corrosion
• ​Maintenance Optimization:

  5-year service life at 250°C
  Hot-swappable connector system

​5. Sensing Operation & Diagnostics​

​High-Temperature Measurement Principle:

1. ​Piezoelectric Conversion:
   • Shear-mode quartz generates charge under acceleration
   • Low thermal sensitivity design minimizes pyroelectric effects
2. ​Signal Transmission:
   • MgO-insulated coaxial cable preserves signal integrity
   • 1m cable length minimizes noise pickup
3. ​Output Options:
   • ​Charge Mode: Direct connection to charge amplifiers
   • ​IEPE Mode: Integrated electronics (optional models)

​Diagnostic & Safety Features:

• ​Built-in Self-Test:
  Insulation resistance monitoring (>10⁹Ω threshold)
  Open-circuit detection via bias current
• ​Failure Modes:
  Output shorts to ground during internal fault
  Hermetic seal failure triggers resistance drop
• ​Calibration Traceability:
  NIST-traceable calibration at 25°C/250°C
  TEDS memory stores calibration coefficients
