Eddy Current Vibration Probe 7mV/mm/s IP67 5M Industrial Sensor

The ProvibTech TM0180-A07-B00-C05-D05 is a rugged vibration transmitter engineered for continuous machinery health monitoring in industrial environments. Featuring an integrated piezoelectric accelerometer (B00 suffix) with ±5% accuracy, this device converts vibration velocity (0-20mm/s RMS) into a 4-20mA output signal (A07 designation) proportional to vibration severity. Its stainless steel housing provides IP67/IP69K protection against dust, moisture, and high-pressure washdowns. The "C05" denotes a 5kHz frequency range with high-pass filtering at 0.5Hz, while "D05" specifies a 5-meter PUR cable for flexible installation. Operating across -40°C to +85°C with ATEX/IECEx Zone 22 certification, it enables predictive maintenance for rotating equipment like pumps, motors, and gearboxes in mining, power generation, and manufacturing facilities.

• Measurement Parameters:
  Velocity Range: 0-20mm/s RMS (±5%)
  Frequency Response: 0.5Hz-5kHz (±3dB)
  Sensitivity: 0.2mA/mm/s
• Electrical:
  Output: 4-20mA loop-powered
  Excitation: 12-30V DC
  Load: ≤600Ω
• Environmental:
  IP67/IP69K (IEC 60529)
  Temperature: -40°C to +85°C
• Mechanical:
  Housing: 316L stainless steel
  Mounting: M10×1.5 threaded stud
  Weight: 85g
• Signal Processing:
  High-pass filter: 0.5Hz (C05)
  RMS conversion time: 1s
• Certifications:
  ATEX II 3G Ex ec IIC T85°C Gc
  IECEx Ex ec IIC T85°C Gc

This transmitter enables predictive maintenance for:

• Centrifugal Pumps: Cavitation detection in chemical processing plants
• Electric Motors: Bearing wear monitoring on conveyor drives
• Gearboxes: Tooth damage identification in mining crushers
• Fans & Blowers: Imbalance detection in HVAC systems
• Compressors: Piston rod misalignment alerts
• Turbines: Blade passing frequency monitoring
• Rolling Mills: Roller bearing degradation tracking
• Paper Machine Drums: Vibration analysis during high-speed operation

Its 4-20mA output integrates directly with PLC/DCS systems for real-time FFT analysis, while the IP69K rating ensures reliability in food processing plants with daily CIP washdowns.

• Plug-and-Play Installation:
  Integrated sensor eliminates alignment/calibration
  5m cable enables remote mounting from vibration source
• Signal Integrity:
  24-bit ADC with anti-aliasing filtering
  <0.1% nonlinearity across full scale
• Environmental Resilience:
  Hermetic laser welding prevents moisture ingress
  Shock resistance: 5,000g (IEC 60068-2-27)
• Diagnostic Capabilities:
  Built-in self-test (BIST) detects sensor faults
  Over-range indication via 22mA signal
• Hazardous Area Safety:
  Intrinsically safe design (Entity Parameters: Ui=30V, Ii=100mA)
  Galvanic isolation >1.5kV
• Maintenance Optimization:
  > 10-year MTBF per IEC 61709
  Tool-free cable replacement
