T77410-10 - Magnetoelectric Speed Sensor - 10V DC IP67 Stainless Industrial Probe

1. Intrinsically Safe Speed Monitoring Solution​

The AI-Tek T77410-10 is an explosion-proof speed sensor engineered for critical rotational monitoring in hazardous industrial environments. Featuring a ​magnetic sensing principle​ with ​10mm detection range, this device generates digital pulses proportional to gear teeth or notch passage with ​​±0.1% accuracy. Its ​stainless steel housing (316L)​​ achieves ​ATEX/IECEx Zone 0/1 certification​ and ​IP67 protection​ against dust, moisture, and temporary submersion. Operating across ​​-40°C to +100°C, the sensor outputs ​NAMUR-compliant signals​ (IEC 60947-5-6) for direct integration with safety systems. The mineral-insulated cable withstands ​150°C surface temperatures, while the hermetically sealed design prevents gas ingress in explosive atmospheres. Designed for oil/gas, mining, and chemical processing applications, it provides reliable speed feedback for turbines, compressors, and conveyors where combustible gases/dusts demand rigorous safety standards.

​2. Critical Technical Specifications​

• ​Sensing Performance:
  Target: Ferrous gear teeth (≥10mm module)
  Sensing Distance: 10mm ±0.5mm
  Frequency Range: 0–10kHz
  Accuracy: ±0.1% of reading
• ​Electrical:
  Voltage: 8-30V DC (loop-powered)
  Output: NAMUR (2-4mA current loop)
  Compliance: IEC 60947-5-6
• ​Environmental:
  IP67 (IEC 60529)
  Temperature: -40°C to +100°C
  Shock Resistance: 100g (IEC 60068-2-27)
• ​Hazardous Area:
  ATEX Ex ia IIC T4 Ga
  IECEx Ex ia IIC T4 Ga
• ​Mechanical:
  Housing: SS316L (EN 1.4404)
  Cable: 2m PUR/mineral-insulated
  Mounting: M18×1.5 threaded

​3. Hazardous Environment Applications​

This sensor serves critical speed monitoring roles:

• ​Offshore Gas Compressors: Shaft speed monitoring in Zone 1 methane atmospheres
• ​Mining Conveyors: Speed verification in combustible dust (Zone 21)
• ​Refinery Turbines: Overspeed protection per API 670 Annex H
• ​Chemical Reactors: Agitator speed control in Zone 0 H₂S environments
• ​Grain Elevators: Conveyor speed interlocks in ATEX Zone 22
• ​Marine Engine Rooms: Propulsion shaft RPM monitoring
• ​Petroleum Storage: Pump speed safety cutoffs
• ​Explosive Manufacturing: Mixer speed verification
  Its Ex ia certification ensures safe operation in continuously explosive atmospheres where standard sensors pose ignition risks, while IP67 rating maintains functionality in washdown areas.

​4. Functional Advantages​

• ​Hazardous Area Safety:
  Intrinsic safety barriers limit energy to <0.03W
  Hermetic seals prevent explosive gas ingress
• ​Signal Reliability:
  NAMUR output enables broken wire detection
  ±1μs pulse timing accuracy
• ​Environmental Durability:
  Resists oils, solvents, and UV degradation
  500hr salt spray resistance (ISO 9227)
• ​Diagnostic Intelligence:
  Dual-color LED indicates power/signal status
  Short-circuit/overload protection
• ​Installation Flexibility:
  360° adjustable sensing head
  ±3mm lateral tolerance alignment
• ​Compliance Efficiency:
  SIL 2 capable per IEC 61508
  Pre-certified for IECEx/ATEX documentation

​5. Speed Sensing Operation​

​Magnetic Sensing Sequence:

1. ​Target Detection:
   • Gear tooth approaches within 10mm → magnetic flux change
2. ​Signal Generation:
   • Hall-effect sensor triggers Schmitt-trigger circuit
   • Pulse width: 50% duty cycle ±5%
3. ​NAMUR Output:
   • Current swing: 2mA (no target) → 4mA (target detected)
   • Open-circuit detection: <1.2mA or >6mA
4. ​Fault Diagnostics:
   • ​Solid Green LED: Power applied
   • ​Flashing Green: Signal detected
   • ​Solid Red: Fault condition
   • ​Flashing Red: Configuration error

​Safety Architecture:

• Galvanic isolation >1.5kV AC
• Output current limited to <8mA
• Automatic shutdown on short circuit
