161546013 PVC Union Check Valve Industrial Water Treatment Corrosion-Proof 150PSI Valve

1. Hygienic Process Flow Measurement Solution​

The GF Signet 161546013 Proline is a sanitary-grade magnetic flow transmitter engineered for precision liquid measurement in pharmaceutical, food, and biotechnology industries. Featuring ​full-bore PTFE lining​ and ​316L stainless steel electrodes, this device delivers ​​±0.5% accuracy​ across ​0.1–60 m/s flow velocities​ with ​​≤100ms response time. Its ​IP69K-rated housing​ provides ​EHEDG Type EL Class I certification​ against high-pressure washdowns (100 bar) and steam sterilization (SIP cycles). The "6013" suffix denotes ​4-20mA + HART 7.5 outputs, ​DN40 tri-clamp connection, and ​SIL 2 compliance​ per IEC 61508. Certified for ​​-20°C to +130°C operation, it incorporates ​empty pipe detection​ and ​bubble tolerance algorithms​ for reliable measurement of conductive liquids ≥5μS/cm. Designed for bioreactors, filling lines, and CIP systems, this transmitter enables bidirectional flow measurement with ​auto-electrode cleaning​ and ​predictive maintenance alerts​ via HART communication while maintaining ​Ra≤0.8µm surface finish​ per ASME BPE standards.

​2. Critical Technical Specifications​

This transmitter operates with ​10–36V DC power​ and consumes ≤3W. Key parameters include ​DN15–DN150 pipe sizes, ​0.001m/s resolution, and ​​±0.2% repeatability. Electrical specifications feature ​1500V AC input-output isolation, ​HART 7.5 digital communication, and ​4kV surge protection. Materials include ​PTFE/PFA liners, ​316L SS/ Hastelloy C276 electrodes, and ​EPDM/FKM seals. Environmental ratings: ​IP69K/NEMA 6P, ​15g shock resistance​ (IEC 60068-2-27), ​5g vibration immunity​ (10–150Hz). Accuracy maintains ​​±0.5% of rate​ at 20°C with ​​<±0.1%/°C temperature drift. Process connection uses ​ISO 2852 tri-clamps​ with self-draining design. Certifications: ​EHEDG, ​3-A 74-03, ​FDA 21 CFR 177.2600, ​ATEX Zone 2/22, ​SIL 2 (PFHD 1×10⁻⁸/h)​. Dimensions: ​185×150×85mm​ with ​15-year MTBF​ at 80°C.

​3. Sanitary Industry Applications​

This transmitter excels in hygienic processing scenarios:

• ​Biopharmaceutical: Perfusion cell culture media flow control
• ​Dairy Processing: Milk transfer line monitoring
• ​Beverage Production: Carbonated drink filling verification
• ​CIP Systems: Chemical circulation rate validation
• ​Vaccine Manufacturing: Buffer solution dosing
• ​Food Processing: Sauce flow accuracy in dispensing
• ​Cosmetic Manufacturing: Lotion flow in filling machines
• ​High-Purity Water: USP WFI distribution monitoring
  Its tri-clamp connections enable quick installation/removal for cleaning validation in GMP environments. The magmeter principle handles viscous fluids (≤20,000cP) like creams and slurries without pressure drop, while PTFE lining resists aggressive chemicals (pH 0–14). SIL 2 certification supports deployment in safety instrumented systems for overfill protection in formulation tanks.

​4. Functional Advantages​

• ​Hygienic Design:
  EHEDG-certified crevice-free flow path (Ra≤0.8µm)
  3° self-draining slope prevents fluid retention
• ​Measurement Reliability:
  Empty pipe detection forces 3.8mA output
  Auto-electrode cleaning via HART command
• ​Diagnostic Intelligence:
  Electrode coating monitoring via impedance analysis
  Liner wear prediction through signal noise trending
• ​Sterilization Resilience:
  Withstands 130°C SIP cycles (30,000+ cycles)
  CIP-compatible with NaOH/PAA/HNO₃
• ​Configuration Flexibility:
  Bidirectional flow totalization with separate registers
  Auto-calibration via dry-run function
• ​Lifecycle Durability:

  15-year electrode lifespan
  No recalibration needed (5-year stability)

​5. Smart Operation & Diagnostics​

​Measurement Principle​ utilizes ​Faraday's Law: Conductive fluid flow through magnetic field induces voltage proportional to velocity. ​HART Diagnostics​ provide real-time:

• ​Electrode Health​ (0–100% integrity index)
• ​Liner Condition​ (wear/crack detection)
• ​Process Noise​ (bubble/particle interference)
  ​Predictive Maintenance Features:
• ​Coating Buildup Alert: >0.1mm thickness triggers cleaning cycle
• ​Flow Profile Analysis: Detects pipe obstructions via turbulence monitoring
• ​Electrode Degradation: Impedance >5kΩ indicates replacement need
  ​Safety Functions:
• ​SIL 2 Overfill Prevention: Trip signal on flow deviation >20%
• ​Fail-Safe State: Forces 22mA output on sensor fault
  ​Communication Protocols:
• ​HART 7.5: Digital parameterization & diagnostics
• ​Modbus RTU: Optional module (161546015)
  ​Validation Support:
• NIST-traceable calibration certificate
• Electronic audit trail (21 CFR Part 11 option)
• Automated validation report generation
