161514632 PVC Union Ball Valve Industrial Water Treatment Corrosion-Resistant 200PSI Valve

1. Precision Process Flow Measurement Solution​

The GF Signet 161514632 Proline is a high-accuracy flow transmitter engineered for critical liquid measurement in industrial process control applications. Featuring ​paddlewheel sensing technology​ with ​316L stainless steel wetted parts, this device delivers ​​±0.5% accuracy​ across ​0.1–100 L/min flow ranges​ and ​​≤100ms response time. Its ​IP67-rated polycarbonate housing​ provides ​NEMA 4X protection​ against dust, water jets, and temporary submersion (1m depth). The "14632" suffix denotes ​4-20mA + HART 7.5 outputs, ​1" NPT process connection, and ​SIL 2 compliance​ per IEC 61508. Certified for ​​-40°C to +85°C operation, it incorporates ​temperature compensation​ and ​bubble rejection algorithms​ for reliable measurement of viscous fluids, slurries, and aerated liquids. Designed for chemical dosing, CIP systems, and water treatment, this transmitter includes ​auto-air purge​ functionality and ​predictive maintenance alerts​ via HART communication while meeting ​EHEDG Type EL Class I​ and ​3-A 74-03 sanitary standards.

​2. Critical Technical Specifications​

This transmitter operates with ​10–36V DC power​ and consumes ≤2W. Key parameters include ​0.1–100 L/min flow range​ (±0.5% of reading), ​0.01 L/min resolution, and ​​<100ms response time. The paddlewheel mechanism provides ​density-compensated mass flow​ without moving parts. Electrical isolation reaches ​1,500V AC​ between process and electronics. Connection utilizes ​M20×1.5 conduit​ with dual-chamber cable gland. Environmental ratings include ​IP67/NEMA 4X, ​15g shock resistance​ (IEC 60068-2-27), and ​5g vibration immunity​ (10–150Hz). Materials feature ​316L SS/TFM/EPDM wetted surfaces​ with ​Ra≤0.8µm finish​ (ASME BPE). Certifications: ​EHEDG, ​3-A Symbol 74-03, ​FDA 21 CFR 177.2600, ​ATEX Zone 2/22, and ​SIL 2 (PFHD 1×10⁻⁸/h)​. Dimensions: ​120×80×60mm​ with ​15-year MTBF​ at 60°C.

​3. Industrial Fluid Control Applications​

This transmitter excels in demanding flow monitoring scenarios:

• ​Chemical Processing: Acid/caustic dosing in pH control loops
• ​Pharmaceutical: Buffer solution transfer in bioreactors
• ​Food & Beverage: Syrup flow verification in filling lines
• ​Water Treatment: Coagulant injection flow validation
• ​HVAC Systems: Chilled water energy monitoring
• ​Pulp & Paper: Black liquor flow measurement
• ​Semiconductor: UPW distribution monitoring
• ​CIP Systems: Chemical circulation rate confirmation
  Its tri-clamp connections enable quick installation/removal for cleaning validation in GMP environments. The paddlewheel design handles viscous fluids (≤1,500cP) like chocolate or adhesives without clogging, while bubble-tolerant algorithms maintain accuracy in carbonated beverages. SIL 2 certification supports deployment in safety instrumented systems for overfill protection in formulation tanks.

​4. Functional Advantages​

• ​Measurement Reliability:
  Viscosity-independent accuracy (±0.5% from 1–1,500cP)
  AutoAir bubble compensation algorithm
• ​Sanitary Design:
  EHEDG-certified crevice-free surface (Ra≤0.8µm)
  Self-draining orientation (3° slope)
• ​Diagnostic Intelligence:
  HART alerts: Coating buildup • Bearing wear • Calibration drift
  Predictive maintenance via totalized flow volume
• ​Configuration Flexibility:
  Teach-in calibration via physical button or HART
  Auto-ranging for variable viscosity applications
• ​Lifecycle Durability:

  10-year bearing lifespan
  Gold-plated contacts prevent oxidation

• ​Maintenance Efficiency:
  Hot-swappable without process interruption
  QR code access to calibration records

​5. Operation & Smart Features​

​Flow Measurement Principle:

1. ​Paddlewheel Rotation:
   Fluid flow → Turbine rotation → Magnetic pickup
2. ​Signal Processing:
   Pulse-to-analog conversion → Temperature compensation
3. ​Output Configuration:

   ​Parameter​	​Output Signal​	​Range​
   Flow Rate	4–20mA	0–100 L/min
   Total Volume	HART variable	0–999,999L
   Fluid Temp	HART variable	-40–85°C

​Advanced Diagnostics:

• ​Bearing Health Monitoring:
  RPM deviation analysis (>10% change alert)
• ​Coating Detection:
  Signal attenuation monitoring (>0.1mm buildup)
• ​Predictive Failure Alerts:
  Usage-based bearing replacement countdown
  ​Communication Protocols:
• ​HART 7.5: Digital parameterization & diagnostics
• ​Modbus RTU: Optional module (161514635)
  ​Calibration & Compliance:
• NIST-traceable calibration certificate
• Electronic audit trail (21 CFR Part 11 option)
• Automatic validation report generation
