NI50U-CP40-AN6X2 50mm Inductive Proximity Sensor IP67 Stainless DC 10-30V Industrial Switch

1. ​Heavy-Duty Dual-Channel Inductive Sensor Overview​

The Turck NI50U-CP40-AN6X2 is a rugged inductive proximity sensor engineered for critical industrial automation applications requiring redundant detection. Featuring a ​nickel-plated brass housing (NI50U suffix)​​ with ​M30×1.5 threading, this device delivers an ​exceptional 40mm sensing range (CP40)​​ for ferrous targets. Its ​dual NPN outputs (AN6X2 designation)​​ provide independent normally open (NO) channels meeting ​SIL 2/PL d safety standards​ (IEC 61508/ISO 13849-1). Certified for ​IP67/IP69K protection, it withstands high-pressure washdowns (150 bar), oils, and temporary submersion while operating across ​​-40°C to +85°C. The sensor incorporates ​cross-monitoring diagnostics​ to detect internal faults and resists vibration (10g) and electromagnetic interference. Designed for safety gates, robotic cells, and heavy machinery, it enables redundant position monitoring where single-point failure could compromise personnel safety or equipment integrity in automotive stamping, mining conveyors, and material handling systems.

2. ​Critical Technical Specifications​

• ​Sensing Performance:
  Range: 40mm for steel (Fe360) ±10%
  Target: Ferrous metals ≥1mm thickness
  Repeatability: ±0.5mm
  Response Frequency: ≤100Hz
• ​Electrical:
  Outputs: 2× NPN NO (sinking)
  Voltage: 10-30V DC
  Switching Current: ≤200mA per channel
  Connection: M12 4-pin connector
• ​Environmental:
  IP67 (IEC 60529) / IP69K (ISO 20653)
  Temperature Range: -40°C to +85°C
  Shock Resistance: 100g (IEC 60068-2-27)
• ​Safety Ratings:
  SIL 2 (PFHD 1.5×10⁻⁸/h per IEC 61508)
  PL d (Cat. 3 per ISO 13849-1)
• ​Mechanical:
  Housing: Nickel-plated brass
  Thread: M30×1.5
  Dimensions: Ø30×80mm

3. ​Industrial Safety Applications​

This sensor excels in high-risk automation scenarios:

• ​Automotive Stamping Presses: Dual-position monitoring of hydraulic rams
• ​Robotic Welding Cells: Safety door position verification
• ​Mining Conveyors: Redundant bucket alignment detection
• ​Packaging Machinery: Guard door interlocks with SIL 2 compliance
• ​Steel Roll Forming Lines: Backup sensing of roller positioning
• ​Hydraulic Presses: Platen position redundancy systems
• ​Material Handling: Pallet presence detection in AS/RS systems
• ​CNC Machine Tools: Tool changer safety interlocks
  Its dual-channel architecture enables use in safety circuits up to PL d where single sensor failure must not compromise protection integrity, particularly in high-vibration environments like forging hammers or crusher plants where 100g shock resistance ensures reliability.

4. ​Functional Advantages​

• ​Redundant Safety Architecture:
  Cross-monitored outputs detect internal faults with >60% diagnostic coverage
  Independent NPN channels meet SIL 2/PL d requirements
• ​Extended Sensing Capability:
  40mm range detects targets through non-metallic barriers
  ±15mm lateral tolerance for misalignment compensation
• ​Environmental Resilience:
  Nickel-plated brass withstands coolants/hydraulic fluids
  IP69K rating survives 1500 psi steam cleaning
• ​Diagnostic Intelligence:
  Dual-color LEDs (green/red) per channel for status indication
  Fault memory via output pulsing patterns
• ​Electrical Robustness:
  Reverse polarity protection (EN 60947-5-2)
  Short-circuit/overload protection per channel
• ​Installation Durability:
  M30 threading withstands 80Nm torque
  500hr salt spray resistance (ISO 9227)

5. ​Safety Operation & Diagnostics​

​Dual-Channel Logic:

1. ​Target Detection:
   Ferrous metal enters 40mm range → electromagnetic field disturbance
2. ​Output Behavior:
   Both NPN channels close (sink current) on detection
3. ​Cross-Monitoring:
   ASIC compares response times (discrepancy >5ms triggers fault)
4. ​Diagnostic Indicators:

   ​LED State​	​Condition​
   Solid Green (both)	Normal operation
   Flashing Green (Ch1)	Channel 1 active
   Solid Red (Ch1)	Channel 1 fault
   Off	Power loss

​Safety Protocol:

• Outputs force open circuit within 10ms of fault detection
• Undervoltage lockout below 8V DC
• Automatic restart after fault clearance
