NI35-CP40-FZ3X2 35mm Inductive Proximity Sensor IP67 Stainless DC 10-30V Industrial Switch

1. ​Dual-Channel Safety Proximity Sensor Overview​

The Turck NI35-CP40-FZ3X2 is a heavy-duty inductive proximity sensor engineered for safety-critical industrial automation applications. Featuring a ​nickel-plated brass housing (NI35 suffix)​​ with ​M30×1.5 threading, this device delivers an ​exceptional 40mm sensing range (CP40)​​ for ferrous targets. Its ​dual PNP outputs (FZ3X2 designation)​​ provide independent normally open (NO) and normally closed (NC) channels meeting ​SIL 2/PL d safety standards​ per IEC 61508/ISO 13849. Certified for ​IP67/IP69K protection, it withstands high-pressure washdowns (150 bar), oils, and temporary submersion while operating across ​​-40°C to +85°C. The sensor incorporates ​cross-monitoring diagnostics​ to detect internal faults and resists vibration (10g) and electromagnetic interference. Designed for safety gates, robotic cells, and heavy machinery, it enables redundant position monitoring where single-point failure could compromise personnel safety or equipment integrity.

2. ​Critical Technical Specifications​

• ​Sensing Performance:
  Range: 40mm for steel (Fe360) ±10%
  Target: Ferrous metals ≥1mm thickness
  Repeatability: ±0.5mm
  Response Frequency: ≤100Hz
• ​Electrical:
  Outputs: 2× PNP (NO + NC independent channels)
  Voltage: 10-55V DC / 20-250V AC
  Switching Current: ≤400mA per channel
• ​Environmental:
  IP67 (IEC 60529) / IP69K (ISO 20653)
  Temperature Range: -40°C to +85°C
  Shock Resistance: 100g (IEC 60068-2-27)
• ​Safety Ratings:
  SIL 2 (PFHD 1.5×10⁻⁸/h per IEC 61508)
  PL d (Cat. 3 per ISO 13849-1)
• ​Mechanical:
  Housing: Nickel-plated brass
  Thread: M30×1.5
  Cable: PUR 2m (oil-resistant)

3. ​Safety-Critical Industrial Applications​

This sensor excels in high-risk automation scenarios requiring redundancy:

• ​Robotic Workcells: Dual-channel safety door position verification
• ​Press Brakes: Redundant guard monitoring for ANSI B11.3 compliance
• ​Automotive Assembly Lines: Safety light curtain bypass prevention
• ​Packaging Machinery: Muting sensor redundancy for high-speed lines
• ​Material Handling: SIL 2-compliant pallet presence detection
• ​Metal Stamping Presses: Dual-input clutch/brake monitoring
• ​Conveyor Systems: Emergency stop verification circuits
• ​Machine Tooling: Safety interlocks for automatic tool changers
  Its dual-channel architecture enables use in safety circuits up to PL d where single sensor failure must not compromise protection integrity, particularly in automotive stamping and robotic assembly applications.

4. ​Functional Safety Advantages​

• ​Dual-Channel Safety Architecture:
  Cross-monitored outputs detect internal faults with >60% diagnostic coverage
  Meets architectural constraints for SIL 2/PL d systems
• ​Extended Sensing Capability:
  40mm range allows detection through non-metallic barriers
  ±15mm lateral tolerance for misalignment compensation
• ​Environmental Resilience:
  Resists hydraulic fluids, coolants, and UV degradation
  IP69K withstands 1500 psi steam cleaning
• ​Diagnostic Intelligence:
  Dual-color LEDs (green/red) per channel for status indication
  Fault memory via output pulsing patterns
• ​Electrical Robustness:
  AC/DC universal voltage operation (10-55V DC/20-250V AC)
  Short-circuit/overload protection per channel
• ​Compliance Efficiency:
  Pre-validated SIL 2/PL d documentation packages
  TÜV-certified safety templates

5. ​Safety Operation & Diagnostics​

​Dual-Channel Logic:

1. ​Target Detection:
   Ferrous metal enters 40mm range → electromagnetic field disturbance
2. ​Output Behavior:
   • ​NO Channel: Closes (sinks current) on detection
   • ​NC Channel: Opens (stops sinking) on detection
3. ​Cross-Monitoring:
   ASIC compares channel response times (discrepancy >5ms triggers fault)
4. ​Diagnostic Indicators:

   ​LED State​	​Condition​
   Solid Green (both)	Normal operation
   Flashing Green (Ch1)	Channel 1 active
   Solid Red (Ch1)	Channel 1 fault
   Solid Red (Ch2)	Channel 2 fault
   Alternating Red	Cross-fault detected

​Safety Response Protocol:

• Outputs force safe state (NO open/NC closed) within 10ms of fault detection
• Undervoltage lockout below 8V DC prevents unsafe operation
• Automatic restart after fault clearance and manual reset
