MX2034 - Eddy Current Vibration Probe - 20mV/mm/s IP67 Stainless Industrial Sensor

1. Advanced DIN-Rail Monitoring System Overview​

The ProvibTech MX2034 is a comprehensive machinery health monitoring system engineered for predictive maintenance in industrial automation. Featuring ​dual-channel IEPE/charge input​ with ​EtherNet/IP and Modbus TCP outputs, this DIN-rail mounted device performs real-time vibration analysis per ISO 10816 standards. Its ​IP66-rated aluminum housing​ (100×110×45mm) withstands harsh environments (-40°C to +85°C) while providing ​ATEX Zone 22 certification. The system measures ​velocity RMS (0-50mm/s)​, ​acceleration (0-100g)​, and ​temperature​ with ​​±0.5% accuracy, integrating FFT spectrum analysis up to 10kHz. Dual 24V DC inputs support redundant power, while integrated web server enables configuration-free commissioning. Designed for continuous monitoring of turbines, compressors, and critical rotating assets in power generation, oil & gas, and heavy manufacturing facilities.

​2. Critical Technical Specifications​

• ​Measurement Capabilities:
  Velocity RMS: 0-50mm/s (±0.5% FS)
  Acceleration: 0-100g peak (±1% FS)
  Temperature: PT100/1000 input (-50°C to +150°C)
• ​Signal Processing:
  24-bit ADC resolution
  FFT: 400/800/1600 lines selectable
  Sampling Rate: 51.2kHz
• ​Electrical Interfaces:
  Power: 18-36V DC (dual redundant)
  Communication: EtherNet/IP, Modbus TCP, USB 2.0
  Inputs: 2× IEPE/charge (4mA constant current)
• ​Environmental:
  IP66 (IEC 60529)
  Operating Temp: -40°C to +85°C
  Shock Resistance: 100g (IEC 60068-2-27)
• ​Certifications:
  ATEX II 3G Ex ec IIC T85°C Gc
  SIL 2 (IEC 61508 PFHD 2.1×10⁻⁸/h)

​3. Industrial Predictive Maintenance Applications​

This system serves critical roles in asset health management:

• ​Power Plant Steam Turbines: Bearing condition monitoring per API 670
• ​Offshore Gas Compressors: Vibration analysis in Zone 22 hazardous areas
• ​Hydroelectric Generators: Thrust bearing health assessment
• ​Mining Conveyor Drives: Gear mesh frequency detection
• ​Refinery Centrifugal Pumps: Cavitation monitoring
• ​Paper Machine Dryers: Roller bearing degradation tracking
• ​Marine Propulsion Engines: Crankshaft vibration analysis
• ​Cement Kiln Drives: Misalignment detection at high temperatures
  Its dual-channel architecture enables simultaneous measurement of casing vibration (velocity) and bearing defects (acceleration envelope), providing comprehensive machinery diagnostics without external analyzers.

​4. Functional Advantages​

• ​Multi-Parameter Monitoring:
  Simultaneous velocity RMS, acceleration envelope, and temperature
  ISO 10816 severity-based alarms with configurable thresholds
• ​Network Integration:
  Real-time data streaming via EtherNet/IP implicit messaging
  Modbus TCP registers for PLC integration
• ​Diagnostic Intelligence:
  Embedded FFT with peak hold and harmonic cursor
  Automatic bearing fault frequency calculation
• ​Environmental Robustness:
  Corrosion-resistant anodized aluminum housing
  Conformal-coated PCBA withstands 95% humidity
• ​Safety Compliance:
  ATEX Zone 22 intrinsically safe design
  Galvanic isolation >1.5kV
• ​Maintenance Optimization:
  SD card slot for data logging (up to 32GB)
  Automatic report generation (PDF/CSV)

​5. Operational Workflow & Safety​

​Monitoring Sequence:

1. ​Signal Acquisition:
   • IEPE sensors powered via constant current (4mA)
   • Charge mode for high-temperature applications
2. ​Processing:
   • Velocity: 10Hz–1kHz bandpass per ISO 10816-1
   • Envelope: 2-10kHz bandpass demodulation
3. ​Analysis:
   • Real-time FFT with Hanning/Hamming windows
   • Crest factor calculation for bearing defects
4. ​Output:
   • 4-20mA proportional to velocity RMS
   • EtherNet/IP produces:
     • Velocity RMS/Peak
     • Acceleration Envelope
     • Temperature
     • FFT spectrum

​Safety & Diagnostics:

• ​Alarm Management:
  Two configurable relays (SPDT 5A)
  Settable thresholds per ISO 10816 severity zones
• ​Fault Detection:

  ​LED Indicator​	​Condition​
  Green	Normal
  Yellow	Warning
  Red	Alarm
  Flashing Red	System fault

• ​Fail-Safe Operation:
  Relays de-energize on power loss
  4-20mA drops to <3.6mA during sensor fault
