TXA-72900 - Eddy Current Vibration Probe - 90mV/mm/s IP67 Stainless Industrial Sensor

1. Extreme-Performance Vibration Sensor Overview​

The ProvibTech TXA-72900 is a high-fidelity IEPE accelerometer engineered for mission-critical vibration monitoring in the most demanding industrial environments. Featuring a ​robust titanium housing (Grade 5 Ti-6Al-4V)​​ with ​integral mineral-insulated cable, this sensor delivers ±1% accuracy across a ​100g measurement range​ with ​50mV/g sensitivity. Its ​hermetically laser-welded construction​ achieves ​IP68/IP69K protection​ against high-pressure washdowns (150 bar), corrosive chemicals (pH 0.5-14), and temporary submersion (3m depth). Operating from ​​-55°C to +150°C​ with ​ATEX/IECEx Zone 21 certification, it incorporates ​TEDS (IEEE 1451.4) memory​ for plug-and-play calibration. Designed for gas turbines, rocket test stands, and heavy mining equipment, this sensor provides uncompromising performance where standard accelerometers fail, with SIL 2 compliance per IEC 61508 ensuring functional safety in critical applications.

​2. Critical Technical Specifications​

• ​Measurement Performance:
  Range: ±100g peak (±1% FS)
  Sensitivity: 50mV/g ±3% @ 25°C
  Frequency Response: 0.5Hz–10kHz (±3dB)
• ​Environmental Resilience:
  IP68 (3m/24hr) / IP69K (150 bar @ 85°C)
  Temperature: -55°C to +150°C (300°C peak)
  Shock Survival: 10,000g (IEC 60068-2-27)
• ​Electrical Specifications:
  Constant Current: 2-20mA (4mA typical)
  Noise Floor: <100μg/√Hz @ 1Hz
  TEDS Memory: Stores calibration/SN/date
• ​Mechanical Construction:
  Housing: Titanium alloy (M5×0.8 threaded)
  Cable: 2m mineral-insulated stainless steel
  Weight: 50g
• ​Phase & Linearity:
  Phase Shift: <1° @ 1kHz
  Non-linearity: <0.5% FS
• ​Certifications:
  ATEX II 2G Ex ia IIC T150°C Ga
  IECEx Ex ia IIC T150°C Ga

​3. Ultra-Demanding Industrial Applications​

This accelerometer excels in extreme operating environments:

• ​Aerospace Test Rigs: Rocket engine vibration monitoring during static fires
• ​Gas Turbine Hot Sections: Blade vibration at 150°C exhaust streams
• ​Hypersonic Wind Tunnels: Shock wave impact measurement
• ​Mining Explosive Drilling: Blast vibration analysis in methane atmospheres
• ​Nuclear Reactor Coolant Pumps: Primary loop surveillance
• ​Steel Continuous Casters: Mold oscillation monitoring at 1400°C proximity
• ​Deep-Sea Mining ROVs: Hydraulic cutter head vibration
• ​Rocket Propulsion Testing: Combustion instability detection
  The titanium housing withstands chloride stress corrosion in offshore environments, while the 150°C continuous rating exceeds standard industrial sensors by 50%, enabling direct mounting on steam turbines and combustion equipment.

​4. Functional Advantages​

• ​Thermal Stability:
  <±0.02%/°C sensitivity drift (-55°C to +150°C)
  Quartz shear-mode design minimizes pyroelectric effects
• ​Signal Integrity:
  Mineral-insulated cable provides 120dB EMI immunity
  Ground loop isolation via double-shielded construction
• ​Hazardous Area Safety:
  Intrinsic safety barriers (Ui=5V, Ii=10mA, Pi=0.015W)
  Explosion-proof containment up to 150°C surface temp
• ​Corrosion Defense:
  Titanium resists H₂S/seawater/pH 0.5-14
  2,000hr salt spray resistance (ISO 9227)
• ​Calibration Efficiency:
  TEDS auto-configuration reduces setup time by 80%
  NIST-traceable calibration included
• ​Mechanical Durability:
  10,000g shock survivability
  Resonance frequency: 35kHz

​5. Sensing Operation & Diagnostics​

​Measurement Workflow:

1. ​Piezoelectric Conversion:
   • Shear-mode quartz generates charge proportional to acceleration
2. ​Signal Conditioning:
   • Ultra-low-noise JFET amplifier
   • 0.5Hz high-pass filter removes thermal drift
3. ​Output Delivery:
   • Voltage output: ±5V full-scale (50mV/g)
   • Current draw: 4mA ±0.5mA indicates health

​Diagnostic Hierarchy:

​Safety Integration:

• Automatic short-circuit protection
• Hermetic seal monitors (resistance <10⁹Ω triggers fault)
• Galvanic isolation >2kV AC
