9282-085-00 - Eddy Current Vibration Probe - 85mV/mm/s IP67 Stainless Industrial Sensor

1. High-Range Vibration Monitoring Solution Overview​

The ProvibTech 9282-085-00 is a heavy-duty vibration transmitter engineered for extreme industrial machinery requiring extended measurement capabilities. Featuring an ​integrated IEPE accelerometer​ and ​4-20mA loop-powered output, this device measures velocity RMS up to ​85mm/s​ with ​​±1% accuracy​ across a ​10Hz–1kHz frequency range. Its ​anodized aluminum housing​ provides ​IP66/IP68 protection​ against dust, high-pressure water jets (100 bar), and temporary submersion (3m depth). Designed for DIN-rail mounting per EN 60715, it operates across ​​-40°C to +85°C​ with ​ATEX/IECEx Zone 22 certification. The transmitter's high-range capability makes it ideal for monitoring crushers, hammer mills, forging presses, and other high-energy equipment where vibration levels exceed standard sensor ranges. SIL 2 compliance per IEC 61508 ensures functional safety in critical power generation and mining applications.

​2. Critical Performance Specifications​

• ​Measurement Range: 0-85mm/s RMS velocity (±1% FS accuracy)
• ​Frequency Response: 10Hz–1kHz (±3dB) with 10Hz high-pass filter
• ​Electrical:
  • 2-wire 4-20mA loop-powered (18-30V DC)
  • 500Ω max loop resistance
  • Reverse polarity protection
• ​Environmental:
  • IP66/IP68 (IEC 60529)
  • Operating Temp: -40°C to +85°C
  • Shock Resistance: 100g (IEC 60068-2-27)
• ​Mechanical:
  • Dimensions: 22.5×90×110mm (W×H×D)
  • DIN-rail mounting (35mm EN 60715)
  • Terminal Blocks: 0.2-2.5mm²
• ​Certifications:
  • ATEX II 3G Ex ec IIC T85°C Gc
  • IECEx Ex ec IIC T85°C Gc
  • SIL 2 (IEC 61508 PFHD 1.5×10⁻⁸/h)

​3. Heavy-Industrial Machinery Applications​

This transmitter excels in monitoring ultra-high-vibration equipment:

• ​Mining Crushers: Primary gyratory crusher monitoring (>60mm/s RMS)
• ​Forging Hammers: Anvil foundation vibration during impact operations
• ​Pulp & Paper: Refiner vibration in chipboard production
• ​Metal Shredders: Rotor imbalance detection in recycling plants
• ​Power Generation: Coal pulverizer gearbox monitoring
• ​Cement Production: Raw mill gear drive surveillance
• ​Steel Manufacturing: Slag granulator vibration analysis
• ​Marine Engineering: Propulsion shaft line monitoring
  Its extended 85mm/s range accommodates severe fault conditions in equipment subject to impact loads, while IP68 rating ensures reliability in quarry dust and mineral processing slurry environments.

​4. Functional Advantages​

• ​High-Energy Resilience:
  Withstands sustained 85mm/s vibration levels (ISO 10816 Severity Zone D)
  Accelerometer survival rating: 500g peak
• ​Environmental Robustness:
  Anodized aluminum housing resists corrosion in pH 3-10 environments
  Conformal-coated electronics withstand 95% humidity
• ​Safety Integration:
  ATEX Zone 22 certification for combustible dust environments
  Galvanic isolation >1.5kV between sensor/loop
• ​Diagnostic Intelligence:
  4mA "live zero" enables cable break detection
  22.5mA output signals over-range conditions (>85mm/s)
• ​Maintenance Optimization:

  15-year MTBF (IEC 61709)
  Solid-state design with no moving parts

• ​Configuration Flexibility:
  DIP-switch selectable damping (0.5s/2s/5s averaging)
  Optional display module for local readout

​5. Signal Processing & Safety Operation​

​Measurement Workflow:

1. ​Vibration Sensing:
   • Piezoelectric crystal generates charge proportional to acceleration
2. ​Velocity Conversion:
   • Analog integration circuit with temperature compensation
   • 10Hz high-pass filter removes structural resonance artifacts
3. ​True RMS Calculation:
   • 1-second moving window per ISO 10816-1
4. ​Output Scaling:
   • 4mA = 0mm/s RMS
   • 20mA = 85mm/s RMS
   • Linear scaling: 0.188mA/mm/s

​Fault Protection System:

• ​Fail-Safe States:

  ​Condition​	​Output Current​	​Alarm State​
  Normal	4-20mA	-
  Sensor Fault	3.6mA ±0.1mA	Critical
  Cable Break	<3.5mA	Critical
  Over-range	21.5-22.0mA	Warning

• ​Automatic Recovery:
  Self-resetting after transient overloads (<5s)
  Manual power cycle required for sensor faults
