tm016-151-132-00-00 - Eddy Current Vibration Probe - 15mV/mm/s IP67 Stainless Industrial Sensor

1. ​Integrated Vibration Monitoring System Overview​

The ProvibTech TM016-151-132-00-00 is a comprehensive machinery health monitor engineered for critical asset protection in industrial automation. Featuring a ​dual-channel IEPE sensor input (151 suffix)​​ and ​4-20mA + HART output (132 designation)​, this device provides simultaneous velocity and acceleration measurements with ​​±1% accuracy. Its ​hardened aluminum housing​ achieves ​IP66/IP68 protection​ against dust, moisture, and temporary submersion (3m depth). The "00-00" suffix denotes ​standard configuration without temperature/relay options. Certified for ​ATEX/IECEx Zone 22​ and operating across ​​-40°C to +85°C, it performs ISO 10816-compliant analysis with configurable alarm thresholds. DIN-rail mounting and integrated signal conditioning enable predictive maintenance for pumps, compressors, and turbines in oil & gas, power generation, and heavy manufacturing facilities requiring SIL 2 reliability.

2. ​Core Technical Specifications​

• ​Measurement Capabilities:
  Velocity Range: 0-25mm/s RMS (±1% FS)
  Acceleration Range: 0-10g peak (±2% FS)
  Frequency Response: 10Hz-1kHz (velocity), 1Hz-5kHz (acceleration)
• ​Electrical Interfaces:
  Output: 4-20mA + HART 7.0
  Sensor Excitation: 24V DC IEPE constant current
  Power Supply: 18-36V DC loop-powered
• ​Environmental Resilience:
  IP66 (dust/water jets) / IP68 (3m/24hr submersion)
  Operating Temperature: -40°C to +85°C
• ​Mechanical Construction:
  Housing: Anodized aluminum alloy (EN AW-6063)
  Dimensions: 110×75×45mm (W×H×D)
  Mounting: DIN-rail EN 60715
• ​Certifications:
  ATEX II 3G Ex ec IIC T85°C Gc
  SIL 2 per IEC 61508 (PFH 1.5×10⁻⁸/h)

3. ​Critical Industrial Applications​

This monitor serves essential roles in high-value asset protection:

• ​Offshore Gas Compressors: Suction/discharge end vibration monitoring per API 670
• ​Power Plant Turbines: Bearing health assessment during load changes
• ​Refinery Centrifugal Pumps: Cavitation detection in ATEX Zone 2 areas
• ​Mining Conveyor Drives: Gearbox tooth fault identification
• ​Marine Propulsion Engines: Crankshaft vibration analysis
• ​Hydroelectric Generators: Thrust bearing monitoring
• ​Chemical Process Pumps: Seal failure prediction
• ​Paper Machine Dryers: Roller bearing degradation tracking
  Its dual-channel capability enables simultaneous measurement of casing vibration (velocity) and high-frequency bearing defects (acceleration), providing comprehensive machinery health insights without additional hardware.

4. ​Predictive Maintenance Advantages​

• ​Dual-Parameter Monitoring:
  Simultaneous velocity (ISO 10816) and acceleration (envelope detection)
  Crest factor calculation for early bearing defect identification
• ​Smart Diagnostics:
  HART protocol transmits:
  • Velocity RMS/Peak
  • Acceleration Envelope
  • Crest Factor
  • Temperature compensation data
• ​Environmental Robustness:
  Corrosion-resistant housing (1000hr salt spray per ISO 9227)
  Conformal-coated electronics withstand 95% humidity
• ​Safety Compliance:
  ATEX Zone 22 intrinsically safe design
  Galvanic isolation >1.5kV AC
• ​Configuration Flexibility:
  Field-configurable ranges via HART communicator
  Auto-calibration to TEDS-enabled sensors
• ​Lifecycle Efficiency:

  12-year MTBF (IEC 61709)
  Hot-swappable sensor connections

5. ​Monitoring Operation & Safety Integration​

​Dual-Channel Measurement Workflow:

1. ​Sensor Input:
   • Channel 1: Velocity RMS (10Hz-1kHz)
   • Channel 2: Acceleration Envelope (1kHz-5kHz)
2. ​Signal Processing:
   • 24-bit ADC conversion per channel
   • DSP calculates ISO-compliant severity levels
3. ​Output Generation:
   • 4-20mA proportional to velocity RMS
   • HART superimposes acceleration envelope values
4. ​Alarm Management:
   Configurable thresholds per ISO 10816 Severity Bands

​Safety Integration:

• ​Fail-Safe Protocols:
  Output clamps at 3.8mA during sensor fault
  HART Alert Code 2 signals critical failures
• ​Diagnostic Hierarchy:

  ​HART Variable​	​Alert Threshold​	​Action​
  Velocity RMS	>18mm/s (Alarm)	Relay trip
  Envelope Level	>5g (Warning)	Log event
  Crest Factor	>3.5 (Bearing defect)	Schedule maintenance
