3-9900.398-1 GF Signet 4 to 20 mA Output Module

3-9900.398-1 GF Signet 4 to 20 mA Output Module

MOQ: 1
Price: Negotiate
Standard Packaging: Carton
Delivery Period: 3-5DAYS
Custom Georg Fischer Piping System 4 to 20 mA Output Module
Payment Method: T/T, L/C
Supply Capacity: 100PCS/MONTHS
Detail Information
Place of Origin
USA
Brand Name
Georg Fischer
Model Number
3-9900.398-1
Condition:
New And Original
Product Type:
Sensor
Brand:
GF Signet
Factory Warranty:
1 Year
Code:
159 001 784
Descriptio:
4 To 20 MA Output Module
Product Description

GF Signet 3-9900.398-1 4 to 20 mA Output Module





Product Description






GF Signet is offering their 3-9900.398-1 4 to 20 mA Output Module which adds a second 4 to 20 mA Output to the 9900 Transmitter.





Product Information






  • Adds a second 4 to 20 mA Output to the 9900 Transmitter (Generation III and newer)

  • Modular design means user only pay for what they need

  • Loop settings are independent thus allowing different

General

Input Channels

One

Input Types

Digital (S3L)

Serial ASCII, TTL level, 9600 bps



Frequency

Range

0.5 to 1500 Hz



Accuracy

0.5% of reading

Measurement Types

Flow, pH/ORP, Conductivity/Resistivity, Salinity, Pressure, Temperature, Level, Dissolved Oxygen, Batch or user-defined (via 8058)

Enclosure and Display

Case Material

PBT

Window

Shatter-resistant glass

Keypad

4 buttons, injection-molded silicone rubber seal

Display

Backlit, 7 and 14-segment

Update Rate

1 s

LCD Contrast

5 settings

Indicators

“Dial-type” digital bar graph. LEDs for Open Collector, Relays and Warning Indicator

Enclosure Size

¼ DIN

Mounting

9900-1P





Panel

¼ DIN, ribbed on four sides for panel mounting clip inside panel, silicon gasket included. Optional rear enclosure with flat cover available for waterproof protection when installed inside a panel.

Wall

Options include 9900-1P installed in pre-wired NEMA enclosure or inside of rear enclosure with hinged cover.

Pipe

Optional Rear Enclosure with hinged cover and 9900-1P for pipe mount installation

Mounting

9900-1



Field (Integral)

Options include yellow universal or integral kits for installation with sensor







Product Photo




3-9900.398-1 GF Signet  4 to 20 mA Output Module 0
