B&R 80VD100PD.C022-01 Industrial Power Module | 80VDC High-Power Density Distribution for Critical Automation Systems

B&R 80VD100PD.C022-01 Industrial Power Module | 80VDC High-Power Density Distribution for Critical Automation Systems

MOQ: 1
Price: $403/piece
Standard Packaging: 100*100*100mm
Delivery Period: 3 day
Payment Method: T/T
Supply Capacity: 1piece in stock
Detail Information
Place of Origin
GERMANY
Brand Name
B&R
Certification
3C
Model Number
80VD100PD.C022-01
Transfer Rate:
10/100 Mbit/s
Ram:
512 MB LPDDR4 SDRAM
Dimensions:
128 X 100 X 62 Mm
Permissible Contact Load:
10 A
Nominal Output Voltage:
24 VDC
Acopos Support:
Yes
Manufacture:
B&R
Product Description

Motor Control Functionality



The 80VD100PD.C022 - 01, identified by its material number, is designed to control 2 servo motors. This dual - motor control feature is highly beneficial in industrial automation scenarios where coordinated movement of multiple motors is required. For example, in robotic arms or precision manufacturing equipment, the ability to control two motors simultaneously ensures accurate and smooth operation. By providing precise control over these motors, it contributes to enhanced productivity and quality in industrial processes.



Interfaces and I/O Features



This device comes equipped with 2 resolver interfaces, which are crucial for providing feedback on the position and speed of the servo motors. This feedback enables more accurate control. Additionally, it has 2 trigger inputs and a motor holding brake connection. The trigger inputs can be used to initiate specific operations in response to external signals, adding flexibility to the control system. The motor holding brake connection ensures that the motors remain stationary when required, preventing unwanted movement. There are also a digital output and another enable input, which further expand the control options.



Power and Module Attributes



The ACOPOSmicro inverter module within this product features an X2X POWERLINK interface, enabling high - speed data transfer in industrial networks. It operates on a 24 - 64 VDC ±25% power supply, which is a wide range suitable for various industrial power sources. With 2 motor connections and a continuous current of 8 A, it can power the two servo motors effectively. It's important to note that terminal blocks need to be ordered separately. This modular design approach allows for customization and easy integration into different industrial setups.




Property

Details

Material Number

80VD100PD.C022 - 01

Motor Control

Controls 2 servo motors, suitable for industrial automation scenarios requiring coordinated multi - motor movement such as in robotic arms and precision manufacturing equipment

Resolver Interfaces

2 resolver interfaces to provide feedback on servo motor position and speed for more accurate control

Trigger Inputs

2 trigger inputs that can initiate specific operations in response to external signals, enhancing control system flexibility

Motor Holding Brake Connection

Ensures motors remain stationary when needed, preventing unwanted movement

Enable Input

Allows for enabling or disabling certain functions in the control system

Digital Output

1 digital output of 24 VDC with 1 A capacity, providing an additional control option

Inverter Module Interface

X2X POWERLINK interface for high - speed data transfer in industrial networks

Power Supply

Operates on a 24 - 64 VDC ±25% power supply, adaptable to various industrial power sources

Motor Connections

2 motor connections with a continuous current of 8 A to effectively power the two servo motors

Terminal Blocks Requirement

Terminal blocks need to be ordered separately, enabling modular customization and easy integration into different industrial setups
