B&R X20BT9400 32-Channel Digital I/O Terminal - EtherCAT-Enabled Bus Coupler for Machine Control | TÜV-Certified

B&R X20BT9400 32-Channel Digital I/O Terminal - EtherCAT-Enabled Bus Coupler for Machine Control | TÜV-Certified

MOQ: 1
Price: 120$/piece
Standard Packaging: 160*110*60mm
Delivery Period: 3 day
Payment Method: T/T
Supply Capacity: 1piece in stock
Detail Information
Place of Origin
GERMANY
Brand Name
B&R
Certification
3C
Model Number
X20BT9400
Weight:
480 G
Data Code:
32 KB
Service:
One-stop Service
Number Of Digital Inputs:
8
Height:
99 Mm
Bus Controller:
POWERLINK (V1/V2) Controlled Node
Quality:
100% Original 100% Brand
Product Description

Product Identification and Basics



The X20BT9400, with its unique material number, is an X2X Link bus transmitter by B&R. It serves as a crucial component for system expansion. Designed to connect an X20 system to an X67 system, it enables seamless integration between these two systems. This device simplifies the process of system expansion, making it an essential part of industrial control setups that require scalability and compatibility between different system components.



Functional Features



One of the key features of the X20BT9400 is its ability to support up to a 100 - m segment length. This allows for flexible installation in large - scale industrial environments. It also provides the supply for internal I/O power and has an integrated X2X Link power supply for the X67 system. This integration means that the previously required X67 system power supply module can be omitted, streamlining the system design and reducing complexity. Additionally, it is designed to operate only on the rightmost slot, which ensures proper functionality and compatibility within the system.



Application and Installation



In practical applications, connecting an X20 system to an X67 system is made straightforward with the X20BT9400. It is simply connected to the end of the X20 block, allowing the X2X Link cable to be clamped. This easy - to - follow installation process reduces the time and effort required for system integration. By using this bus transmitter, industrial control system designers can enhance the connectivity and expandability of their systems, ultimately improving the overall efficiency and performance of the industrial processes they manage.




Category
Details
General Information

- Material Number
X20BT9400
- Brand
B&R
- Product Type
X2X Link Bus Transmitter
- Function
To connect X20 system to X67 system for seamless system expansion and provide power supply related functions
- Warranty
Usually 12 months (varies by region and distributor)
Electrical Specifications

- Input Voltage
24 VDC (-15% / +20%)
- Input Current
Max. 0.5 A
- Power Consumption - Bus
0.5 W
- Nominal Output Voltage
24 VDC
- Permissible Contact Load
10 A
- Overload Protection
Temporary short - circuit and overload protection, with status indication via LED “I” or software status evaluation
- Power Supply for X67 System
Integrated X2X Link power supply for X67 system; can replace the previously required X67 system power supply module
- Power for Internal I/O
Supplies power for internal I/O
Expansion - related Features

- Segment Length
Up to 100 m segment length, allowing for flexible installation in large - scale industrial setups
- Installation Slot Requirement
Operates only on the rightmost slot to ensure proper functionality and compatibility within the system
- Connectivity
Connects to the end of the X20 block to enable clamping of the X2X Link cable for system connection
Mechanical and Mounting

- Mounting Direction
Horizontal and vertical mounting are both possible
- Installation Elevation
0 - 2000 m: no limitation; > 2000 m: ambient temperature reduction of 0.5 °C per 100 m
- Dimensions
Specific dimensions not provided in the given sources, but designed to fit standard industrial DIN - rail or similar mounting structures
- Weight
Shipping weight is approximately 2 kg (including packaging); actual product weight may vary slightly
- Protection Class
IP20 according to EN 60529, protecting against solid objects larger than 12 mm and preventing accidental contact with live parts
Environmental Conditions

- Operating Temperature
Horizontal installation: - 25 °C to 60 °C; Vertical installation: - 25 °C to 50 °C
- Storage Temperature
- 40 °C to 85 °C
- Transportation Temperature
- 40 °C to 85 °C
- Relative Humidity
5% - 95%, non - condensing during operation, storage, and transportation
- Vibration and Shock Resistance
Designed to withstand normal industrial vibrations and shocks; specific values not provided in the given sources but compliant with relevant industrial standards
Status and Indication

- Status Indicators
Has status indicators for I/O function per channel, operating state, and module status
- Diagnostics
Capable of providing module run/error and input diagnostics, likely through LED status indicators and software (details may vary based on the overall system setup)
Certifications

- Compliance
Meets relevant industry standards; specific certifications not fully detailed in the given sources but expected to comply with safety, EMC, and other relevant industrial regulations
