B&R 0TB1210.3100 Connector 3.5 10p clamp
  • Name
  • Name
  • Name

B&R 0TB1210.3100 Connector 3.5 10p clamp

MOQ: 1pc
Price: $1 -$100
Standard Packaging: new in box
Delivery Period: 3-5days
Two-Row 10-Pin Terminal Block Tb1210 Number Of Pins 10 (Female)
Payment Method: T/T, L/C
Supply Capacity: 30pcs/month
Details Information
Product Description
Detail Information
Place of Origin
Austria
Brand Name
B&R
Model Number
0TB1210.3100
Warranty:
1year
Number Of Pins:
10 (female)
Type Of Terminal Block:
Push-in Spring Connection
Cable Type:
Only Copper Wires (no Aluminum Wires!)
Pitch:
3.5 Mm
Nominal Voltage:
300 V
Product Description

B&R 0TB1210.3100 Connector 3.5 10p clamp 0B&R 0TB1210.3100 Connector 3.5 10p clamp 1B&R 0TB1210.3100 Connector 3.5 10p clamp 2

MATERIAL NUMBER:
0TB1210.3100
DESCRIPTION:

Two-row 10-pin terminal block TB1210 is used to connect to the button/switch interface of the Automation Panel 9xD and to the intes of rfacevarious interface options.

Certifications
CE Yes
UKCA Yes
UL cULus E115267
Industrial control equipment
HazLoc cULus HazLoc E180196
Industrial control equipment
for hazardous locations
Class I, Division 2, Groups ABCD, T4
DNV Temperature: B(0 to 55°C)
Humidity: B(up to 100%)
Vibration: A(0.7 g)
EMC: B(bridge and open deck)
LR ENV3
KR Yes
ABS Yes
BV EC31B
Temperature: 5 - 55°C
Vibration: 0.7 g
EMC: Bridge and open deck
EAC Yes
Terminal block
Note Nominal data per UL
Number of pins 10 (female)
Type of terminal block Push-in spring connection
Cable type Only copper wires (no aluminum wires!)
Pitch 3.5 mm
Connection cross section
AWG wire 26 to 16 AWG
Wire end sleeves with plastic covering 0.14 to 1 mm²
Single-wire 0.14 to 1.5 mm²
Fine-stranded wires 0.14 to 1.5 mm²
With wire end sleeves 0.14 to 1.5 mm²
Electrical properties
Nominal voltage 300 V
Nominal current 10 A
Operating conditions
Pollution degree per EN 61131-2 Pollution degree 2



Tags:

B&R PLC systems,

B&R I/O systems,

B&R Industrial PCs
